FKE-F07 Diesel And Gasoline Pump

3-piston alternating volumetric pumps for use on cleaning units and industrial systems. It can be coupled to various types of motors, directly or with flexible joints. Pump body and cover in die-cast aluminum alloy. The side cover may be blind or incorporate oil sight glass. Rear cover with an oil drain outlet. Pistons driven by crank-connecting rod mechanism. Pump shaft in pressed high-strength steel. Oversized friction bearings. Connecting rods in die-cast special low-friction zinc-aluminium alloy. One-piece ceramic pistons. Pump head in pressed brass—double gasket sealing system. Intake and delivery valves have plugs for easier maintenance.

Contact us

PREV：FKET-F05 Integrated Switch Regular PumpNEXT：FKE-F06 Diesel And Gasoline Pump
Product Roadmap

Product Data

● FKE-F07.3440rpm C version Ø25.4mm

Model FloW Pressure Power Speed Inlet Outlet Weight
L/min gpm bar psi hp kw rpm thread thread KG
FKE1825 18 4.9 250 3600 13 9.8 3440 G1/2" G3/8" 7.7
FKE2420 24 6.4 200 2900 13 9.8 3440 G1/2" G3/8" 7.7
Related products
About
Taizhou Feike Mechanical Technology Co., Ltd.

Feike is a factory specializing in making triplex plunger pumps in Taizhou, Zhejiang, China. We have high precision Automatic TAKAM CNC machines and 3D coordinate no-contact detection machine to ensure the quality of the Pump heads, Crankshaft cases, and valves for the pumps. We have 4 assembly lines so far. Three production lines for triplex pumps separated by high pressure, mid pressure, and low pressure. And one production line for safety valves and regulating valves. We use fixtures to ensure the assembly quality of the ceramic plungers. Air tightness testing is applied for every single semi-finished pump before injecting the lubrication oil.

And every single triplex plunger pump will be tested with an electric motor for running about 15 minutes before final packing. We use lasing to carve the ID numbers on the surface of the pump for tracking. Every final pump is packed with an air bag to protect the pump from damage in the transportation. We can produce about 6000 triplex plunger pumps a month. Welcome to inquiry about our products. We are looking forward to cooperating with you.
